Spektrum Firma 1900Kv Brushless Motor (SPMXSM1600)

Spektrum Firma 1900Kv Brushless Motor (SPMXSM1600)

Overview The Firma 1900Kv brushless motor is a perfect option for 1/8 scale buggy, truggy or monster...
Availability: Out Of Stock
$104.99
$104.99
10 customers are viewing this product
Spektrum Firma 1900Kv Brushless Motor (SPMXSM1600)

Spektrum Firma 1900Kv Brushless Motor (SPMXSM1600)

$104.99
Spektrum Firma 1900Kv Brushless Motor (SPMXSM1600)

Spektrum Firma 1900Kv Brushless Motor (SPMXSM1600)

$104.99
Description
Description
x

Overview

The Firma 1900Kv brushless motor is a perfect option for 1/8 scale buggy, truggy or monster trucks with a 3S-6S LiPo powered setup. Featuring a low cog 4-pole 8-magnet rotor design, CNC machined aluminum housing, insulated high purity copper windings, high-quality alloy steel 4mm output shaft, and precision bearings for high durability and smooth rotation. Preinstalled with 4mm gold plated bullet connectors for easy installation, and perfectly matched for the Firma 130 Smart ESC.

Features

  • Perfect upgrade for 1/8 scale racers and bashers
  • Safe-D Shaft provides a C-clip locking point to prevent pinion gear slip
  • High efficiency design
  • 6S LiPo power capable
  • High-quality 4-pole sintered rotor
  • 4mm gold plated bullet connectors
  • High-quality construction with precision ball bearings and hardened steel 5mm shaft

Product Specifications

Bushing Or Bearing Bearing
Application Upgrade for 1/8 scale racers and bashers with 3-6S Lipo powered setup
Number of Poles 4
Output 4940W
Product Weight 14.67 oz (416 g)
Shaft Diameter 0.19" (5 mm)
Maximum Continuous Current 60A
Motor Type Brushless - Sensorless
Connector Type 4mm Bullet
Efficiency 86%
Motor Size 4274
Product Length 2.9" (74 mm)
Input Voltage 11.1 - 22.2V
RPM/Volt (Kv) 1900Kv
Shaft Length 0.73 in (18.5 mm)
Outer Diameter 1.6 in (42 mm)
Motor Design Inrunner
Scale 1/8
